SIZE
- Flow Rate = up to 30 gpm
- Reservoir Size = 4 gallons
- Basic Dimensions = 22” Long x 10” Wide x 22” Tall
- Weight (dry) = 62 lbs (dry)
FEATURES
- Heat Rejection Rate = 10 Hp @ 30 gpm with 50°F Exitng Temperature Difference (ETD)
- Fan motor = Hydraulic drive requires 2 gpm
- Corrosion Resistant components with SS case
- 10 micron Filer Element
- Adjustable Pressure Relief Valve 500-3000 psi
- 5″ Oil Level Sight Glass
PORTS
- Suction Port = SAE-24 Female
- High Pressure Port = JIC-12 Male
- Return Port = JIC-12 Male
- Drain Port = SAE-8
